Section Thickness Range

1μm~60μm
     1μm~10μm increment 1μm
     10μm~20μm increment 2μm
     20μm~60μm increment 5μm

Trimming Thickness Range

10μm and 30μm

Specimen Retraction

60μm

Horizontal Stroke

28mm

Vertical Stroke

70mm

Maximum specimen size

60*50*40mm

Specimen Orientation

Horizontally/Vertical 8°

Weight

35kg(Net)

Dimensions(W×D×H)

470×560×320mm
